02/065–10nm TiO₂ · Ag⁺ · TVOC

Nano Photocatalyst Coating & Commercial TVOC Neutralizers

Photocatalytic coatings deposit an optically transparent 5–10nm anatase nano-TiO₂ film that continuously mineralizes airborne formaldehyde, TVOC, and surface bacteria under standard indoor LED or daylight illumination. This 5-Product line combines permanent catalytic wall shields — including an Ag⁺ silver-ion dark-active grade for healthcare and hospitality — with rapid-acting TVOC chelators engineered for fresh latex paint, SBR-backed commercial carpets, and large-scale pre-handover engineering.

Request line samplesSee 5 formulations
Sunlit interior walls where visible-light photocatalyst coatings work

In this line

01The range

TVOC & Photocatalyst: 5 formulations.

Compare target pollutants, dosage and pack range, then open a product for its full technical data sheet.

Compare with other lines

Compare the tvoc & photocatalyst range

TVOC & Photocatalytic Coatings: formulations compared
TVOC EliminatorNano Photocatalyst SprayTotal VOC EliminatorAg+ Antibacterial PhotocatalystCarpet & Paint VOC Neutralizer
Product lineTVOC & Photocatalytic CoatingsTVOC & Photocatalytic CoatingsTVOC & Photocatalytic CoatingsTVOC & Photocatalytic CoatingsTVOC & Photocatalytic Coatings
TechnologyBroad-spectrum VOC neutralizerVisible-light nano TiO₂Engineering-grade VOC treatmentAg⁺ dark-active photocatalystCarpet & paint VOC specialist
Target pollutantsTVOCFormaldehyde, TVOC, Bacteria & moldTVOCFormaldehyde, TVOC, Bacteria & moldTVOC, Odor & ammonia
ApplicationsPost-renovation, Commercial & HVAC, Hotel & hospitalityPost-renovation, Commercial & HVAC, Schools & healthcareCommercial & HVACSchools & healthcare, Hotel & hospitalityPost-renovation, Commercial & HVAC, Hotel & hospitality
FormatLiquid sprayLiquid sprayLiquid sprayLiquid sprayLiquid spray
Coverage10–20 ml/m²8–12 ml/m²15–25 ml/m²8–12 ml/m²10–25 ml/m²
Pack range1 L – 200 L1 L – 200 L5 L – 200 L1 L – 200 L1 L – 200 L
Application methodFine HVLP / ULV mist atomization (0.5mm–0.8mm nozzle) across large surface zones0.5mm–0.8mm HVLP precision spray gun at 30–40 cm distanceHigh-throughput HVLP / ULV spray systems across commercial floorplates0.5mm precision HVLP spray gun at 0.25 MPa air pressure0.6mm–0.8mm HVLP spray gun across carpet pile and painted walls
TiO₂ + hν → •OH → CO₂ + H₂O

Visible-light photocatalysis

02How it works

The chemistry behind the line.

Under 400–550nm visible light or UV light, nano-TiO₂ excites electron-hole pairs that generate hydroxyl radicals (•OH) and superoxide anions (O₂⁻), oxidizing volatile organic compounds into harmless CO₂ and H₂O without consuming the catalyst film. Chelated 150 ppm Ag⁺ silver ions provide 24-hour dark-phase antibacterial and mold inhibition, while β-cyclodextrin and plant-extract TVOC neutralizers deliver immediate 24–48h knockdown of alkanes, esters, styrene, and 4-PCH.

Light on a TiO₂ film creates hydroxyl radicals that turn VOCs into CO₂ and H₂Oindoor LED / daylightwall5–10 nm TiO₂ film•OH•OH•OHVOC / HCHOCO₂H₂O
Visible-light photocatalysis: indoor light excites the TiO₂ film, which forms hydroxyl radicals (•OH) at the surface; they oxidise formaldehyde and VOCs to CO₂ and water while the catalyst itself is not consumed.
Particle size comparison: TiO₂ sol 5–10 nm, conventional suspensions over 50 nm, bacterium about 1 µm, hair about 70 µm1 nm10 nm100 nm1 µm10 µm100 µm5–10 nmAnatase TiO₂ sol (ours)> 50 nmConventional powder suspension≈ 1 µmTypical bacterium≈ 70 µmHuman hair width
Particle size on a log scale. Particles far smaller than the wavelength of visible light (400–700 nm) scatter very little of it, which is why a 5–10 nm sol dries to a transparent film instead of a white haze.

03Quantity estimate

Plan quantities before you quote.

Published coverage: 10 – 20 ml/m² depending on coating thickness and baseline TVOC reading

Application passes

Use 2–3 passes for raw high-density board or heavy TVOC loads.

Estimated quantity

3.0–6.0L

10–20 ml/m² × 300 m² × 1 pass

Suggested packs2 × 5 L jerrycans
Quote this quantity

Estimate from the published coverage range. Real consumption depends on substrate porosity, nozzle size and baseline readings — our engineers confirm it with your quote.

Coverage per pass in this line

Published coverage per application pass, in ml per m² of treated surface. Products dosed per unit or by weight are not shown.

04Questions

About tvoc & photocatalyst.

Ask an engineer
01How long does a nano-TiO₂ photocatalyst coating remain active?

Because titanium dioxide acts as a heterogeneous catalyst rather than a consumable reactant, an undisturbed 5–10nm TiO₂ film applied via 0.5mm HVLP atomization remains active for years as long as the wall or ceiling is not repainted or abraded.

02Does your photocatalyst spray work under indoor LED lighting without direct sunlight?

Yes. Our visible-light-doped anatase TiO₂ sol activates under standard 400–550nm indoor LED and fluorescent fixtures. For windowless corridors, wardrobes, or 24/7 clinical sanitation, specify Silver-Ion (Ag⁺) Antibacterial Photocatalyst Spray.

03Which formulation targets new commercial carpet smell (4-PCH) and fresh latex paint?

Carpet & Latex Paint VOC Neutralizer specifically encapsulates and oxidizes 4-phenylcyclohexene (4-PCH) from SBR carpet backing as well as residual acrylic and ester monomers from architectural wall coatings.

Engineering journal

Technical guides for tvoc & photocatalyst.

Reaction kinetics, substrate dosing calculations and closed-room verification protocols for this product line.
